Product Details:
Payment & Shipping Terms:
|
| Product Name: | 20 Feet Semi-automatic Container Spreader For Lifting 20feet Containers | Application: | Containers Lifting |
|---|---|---|---|
| Standard: | ISO9001 | Feature: | Mechanical Control |
| Slings: | BV/CCS Certificate | Color: | Follow The Requirement Of Customer |
| High Light: | container lifting equipment,container lifting spreader |
||
20 feet Semi-automatic Container Spreader for Lifting 20feet Containers
Specifications:
|
Suit for container |
20feet |
|
|
Spreader SWL |
32t |
|
|
Spreader Dead Weight |
2.1t |
|
|
Dia. Of ropes |
32mm |
|
|
Length of spreader |
6054mm |
|
|
Width of spreader |
2438mm |
|
|
Height of spreader |
680mm |
|
|
Min. Working height |
3500mm |
Description:
The semi-automatic container spreader is designed for the handling of 20 ft & 40 ft ISO containers with single or double hook jib cranes, in ports or on vessels. The twistlocks are activated by landing and lifting the spreader from the container by the crane operator.
No hydraulic or electric systems are needed.
Available in 20' and 40' versions to handle 20-40 ISO containers.Capacity up to 36 Tons,Light weight spreader 20' Spreader - 2.2t 40' Spreader - 3.2t
The Semi-Automatic container spreader is used to handle ISO containers.The fixed frame is mounted to a crane by bridle sling and provides a simple way to load and unload containers. Great for ports who need to handle containerson and off a ship, but have lower lift counts.
Applications:
Container ships, port, logistics company
Competitive Advantage:
Easy operation/Strong structure/Less malfunction/BV,CCS certificate supply
